eLink 100

Professional Grade Wireless Extender for HDMI

The Extron eLink 100 professional-grade wireless transmitter and receiver set is designed for AV environments that require extension of HDMI video and multi-channel audio signals up to 100 feet (30 meters). Unlike consumer wireless products, it features a robust wireless communication technology that provides reliable operation and exceptional image quality with latency of less than one millisecond for real-time performance. Other integrator-friendly features include use of the 5 GHz spectrum for signal extension through walls, AES-128 encryption, and commercial-grade components to ensure continuous, secure operation. These capabilities allow up to four eLink 100 extender sets to operate within the same space. Also, one transmitter can support multiple receivers, allowing an AV signal to be distributed to as many as four displays. Extron eLink™ technology ensures reliable operation in the presence of the facility’s other wireless systems, which can include WLAN, smartphones, tablets, and additional eLink 100 extenders. This professional-grade extender is backed by Extron's award-winning service and support.

Key Features

• Reliable, professional-grade wireless extension of HDMI video and multi-channel audio signals up to 100 feet (30 meters)
• Capable of transmitting through multiple walls and furniture
• Supports computer and video up to 1920x1080, including HDTV 1080p/60
• HDCP Compliant
• Ultra-low latency transmission of video and audio signals
• Professional-grade technology enables simultaneous transmission from one transmitter to as many as four independent receivers
• AES 128-bit Data Encryption
• Actively monitors RF spectrum to select the ideal transmission channels
• Supports multiple embedded audio formats
• Multi-input and multi-output, or MIMO, wireless technology provides robust connection
• eLink wireless technologies allow as many as four transmitter and receiver sets to operate within the same space
